3.3 Connections
Connections
Cold Water
Water quality Water quality Drinking water with max
5°dH without softener
Water with 5°dH-35°dH with softener.
Connection G 1/2”
Pressure 100-800 kPa
Flow rate min 20 l/min
Hot Water
Water quality Preheated drinking water with a max
5°dH 45°C-60°C (113°F-140°F) without
softener.
Water with 5°dH-35°dH 45°C-60°C
(113°F-140°F) with softener.
Connection G 1/2”
Pressure 100-800 kPa
Flow rate min 20 l/min
Treated water
Temperature max 60°C (140°F)
Connection G 1/2”
Pressure 100-800 kPa
Flow rate min 20 l/min
The maximum conductivity is
determined by the desired cleaning
results.
Dosage
Pump accuracy ±10%
Drainage
Connection x2 Ø 20 mm inside
Ø 25 mm outside
Capacity 50 l/min
Residual volume in the
chamber
Max. 0.5 liters.
Electrical connections See section 2.6 Connecting electric
power.
3 TECHNICAL DATA
32 (48) INSTALLATION MANUAL GETINGE WD15 CLARO
<Doc_INS><Doc_6001396702><Rev.I><Lang_en>
