CONTROL UNIT -
55
Close
Close machine door.
More
Optional when alarms or
preprogrammed functions are
active.
Alarm-
handling
Silence alarm
signal
Switch alarm signal off.
Informa-
tion
Cycle
information
Provides information about
current process and phase, as well
as the time these have been going
on for. The information is
displayed on the top left.
Messages Displayed if an incident occurs.
The message is displayed in a blue
text box on the left of the
indicators.
Other
points
Save
Save changes and inputted values.
Numeric keyboard
Shift from alphabetic to numeric
keyboard.
Alphabetic
keyboard
Shift from alphabetic to numeric
keyboard.
Right
and
left
arrow
Move the cursor in the input
window.
Zoom in/out
Enlarge/reduce plot graph.
Insufficient user
access
No authorization for accessing the
menu.
