Inspections
Functional tests
6
Maquet PowerLEDII
01810 EN 03
47 / 56
Camera mounts
Fig.60: Electrical safety test of the camera mounts
• For an SC05 camera mount, the measurement should be made between the flange 1 and
the screws located on top of the camera mount 2 .
• For a camera mount installed on an FHS0 monitor mount, the measurement should be made
between the flange 1 and the monitor mount mounting screws 3 .
6.3 Functional tests
NOTICE
Protective goggles [minimum UV Class2 (EN170) – Optical Class1 – Orange
shade] are recommended during installation and maintenance work on sur-
gical lights.
• All LEDs operate correctly
• Check that all lighthead keypad functions are working correctly.
• Check that all wall-mounted keypad functions are working correctly
• Check that all touchscreen functions are working correctly
• The camera, if installed, is working properly (video and zoom)
• Switch over to battery mode and back to mains.
