Gigabyte GA-Z77N-WIFI User Manual

BIOS Setup - 36 -
& Hyper-Threading Technology
(Note 1)
Allows you to determine whether to enable multi-threading technology when using an Intel CPU that supports
this function. This feature only works for operating systems that support multi-processor mode. Auto lets
WKH%,26DXWRPDWLFDOO\FRQ¿JXUHWKLVVHWWLQJ'HIDXOW$XWR
& CPU Enhanced Halt (C1E)
(Note 1)
Enables or disables Intel CPU Enhanced Halt (C1E) function, a CPU power-saving function in system
halt state. When enabled, the CPU core frequency and voltage will be reduced during system halt state to
decrease power consumption. AutoOHWVWKH%,26DXWRPDWLFDOO\FRQ¿JXUHWKLVVHWWLQJ'HIDXOW$XWR
& C3/C6 State Support
(Note 1)
Allows you to determine whether to let the CPU enter C3/C6 mode in system halt state. When enabled, the
CPU core frequency and voltage will be reduced during system halt state to decrease power consumption.
The C3/C6 state is a more enhanced power-saving state than C1. AutoOHWVWKH%,26DXWRPDWLFDOO\FRQ¿JXUH
this setting. (Default: Auto)
& CPU Thermal Monitor
(Note 1)
Enables or disables Intel CPU Thermal Monitor function, a CPU overheating protection function. When
enabled, the CPU core frequency and voltage will be reduced when the CPU is overheated. Auto lets the
%,26DXWRPDWLFDOO\FRQ¿JXUHWKLVVHWWLQJ'HIDXOW$XWR
& CPU EIST Function
(Note 1)
Enables or disables Enhanced Intel SpeedStep Technology (EIST). Depending on CPU loading, Intel EIST
technology can dynamically and effectively lower the CPU voltage and core frequency to decrease average
power consumption and heat production. AutoOHWVWKH%,26DXWRPDWLFDOO\FRQ¿JXUHWKLVVHWWLQJ'HIDXOW
Auto)
& ([WUHPH0HPRU\3URÀOH;03
(Note 2)
Allows the BIOS to read the SPD data on XMP memory module(s) to enhance memory performance when
enabled.
Disabled Disables this function. (Default)
3UR¿OH  8VHV3UR¿OHVHWWLQJV
3UR¿OH
(Note 2)
 8VHV3UR¿OHVHWWLQJV
& System Memory Multiplier
Allows you to set the system memory multiplier. Auto sets memory multiplier according to memory SPD
data. (Default: Auto)
& Memory Frequency (MHz)
 7KH¿UVWPHPRU\IUHTXHQF\YDOXHLVWKHQRUPDORSHUDWLQJIUHTXHQF\RIWKHPHPRU\EHLQJXVHGWKHVHFRQG
is the memory frequency that is automatically adjusted according to the System Memory Multiplier settings.
(Note 1) This item is present only when you install a CPU that supports this feature. For more information
about Intel CPUs' unique features, please visit Intel's website.
(Note 2) This item is present only when you install a CPU and a memory module that support this feature.

Gigabyte GA-Z77N-WIFI Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
S/PDIF out connector	Yes
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	4
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z77
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Compatible operating systems	Windows 8/7/XP
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	-
Bundled software	Norton Internet Security (OEM version), Intel Rapid Start Technology, Intel Smart Connect Technology, Intel Smart Response Technology
Networking features	Gigabit Ethernet, WLAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI

Weight and Dimensions

Width	170 mm
