MDE-4784D FlexPay™ Encrypting PIN Pad Start-up and Service Manual · December 2011 Page 47
Using the FlexPay EPP Mapping Tool Start-up and Service
17 Enter the required information in the following fields in “EPP Operation”:
•Type
•_Brand
• @ Location
• [ POS... ]
• _T Prod. ID
• -Serial number
Note: The key map file name component fields display the following features:
• The first letter of the “_T Prod. ID” field must be a numerical.
• The “Serial number” will be enabled only when the “_T Prod. ID” field is filled.
• The system automatically removes \, /, :, *, ?, “, <, >, and letters which are illegal to
be used in a file name.
• The system automatically replaces “[” and “(” with “{” , and “]” and “)” with
“}”, as they may cause a problem when building a DOS batch file name.
• The system automatically replaces ‘ ’ (space) with ‘_’, but not in the “Type” field.
• The system automatically replaces ‘_’ with ‘-’ in the “Type” field.
18 Click File and Send key map to save the map and generate an .aut file. The Mapping window
is displayed, which indicates the number of unused/unmapped keys and the default Key Codes
on the FlexPay EPP.
Figure 3-46: Saving the Key Map
