GL-INET Opal User Manual

Page 2 | 153
Note: Hot plug for TF card is not supported. If you want to use TF card, please
insert before powering on the router.
1.2. Connect
You can connect to the router via Ethernet cable or Wi-Fi.
Note: This step only connects your devices to the local area network (LAN) of the
router. You cannot access the Internet currently. In order to connect to the Internet,
please finish the setup procedures below and then follow Internet to set up an
Internet connection.
(1) Connect via LAN
Connect your device to the LAN port of the router via Ethernet cable.

GL-INET Opal Specifications

General

RAM	128 MB DDR2
WiFi	802.11b/g/n
USB Port	1 x USB 2.0
VPN Support	OpenVPN, WireGuard
Operating System	OpenWrt
Processor	QCA9531, 650MHz
Flash Storage	16 MB
Ethernet Ports	2 x 10/100 Mbps
Power Input	5V/2A
