Rev.: 4, Print date: 2021-05-05
13
NL95
PANEL
CUT-OUT
3.3 Mounting
3.3.1 Main unit
Make cut-out according to section “7.1 Units outlines/ codes”
Insert main unit into cut-out.
2
3.3.2 Power Supply and Input modules
- Fixing main unit to console with 4 pcs of M5 nuts, mounted from the back of the console. Use lock washers.
- Check if the main unit is properly fixed
1
1
2
POWER ON
FAILURE
F1
for bolts M6
for bolts M6
