OPERATOR MAINTENANCEUSER HANDBOOK
CHARGING
CONTACTS
INSTRUMENT HANDLE
STORAGE CLIP
SECURING
STRAP
EXTENSION POLE LOCATION
IN INSTRUMENT HANDLE
Fig 13.20 Charging Station - Instrument Location
4) Insert probe in location in charging station, as shown in Fig.
13.20.
5) If permanent 12V power supply is not installed, connect
power supply, i.e. Universal Power Supply (Part No.12444)
or 12V Vehicle Power Supply (Part No.12988), to socket in
LH side panel of Charging Station as shown in Fig. 13.21.
