ENG
4.0
GLT
Ω
L
IFT
O
PERATION AND
M
AINTENANCE
M
ANUAL
Page | 18
3 PUSH-BUTTON PANELS
The following push-button panels can be installed in the lift:
• Push-button panels for lift with universal operation;
• Push-button panels for lift with collective down operation;
• Push-button panels for lift with collective up-down operation.
3.1 PUSH-BUTTON PANELS FOR LIFT WITH UNIVERSAL OPERATION
The push-button panel for a lift with universal operation consists of the following.
The following buttons and indicators (minimum supply) are provided on the floors:
• Call button, which the user must press to call the lift;
• In use signal or blue indicator, showing that the lift is not immediately available.
The following buttons and indicators are in the car:
• Button with floor number;
• Yellow alarm button with bell symbol;
• Door reopening button with outline of double arrow;
• Luminous car position signal;
• Luminous and audible car overload signal.
3.2 PUSH-BUTTON PANELS FOR LIFT WITH COLLECTIVE DOWN
OPERATION
The push-button panel for a lift with collective down operation consists of the following.
The following buttons and indicators (minimum supply) are provided on the floors:
• Call accepted button, which the user must press to call the lift;
• “Call accepted” signal or blue indicator, showing that the call for the lift has been accepted;
• Luminous arrows showing the directions of movement.
The following buttons and indicators are in the car:
• Call accepted buttons with floor number;
• Yellow alarm button with bell symbol;
• Door reopening button with outline of double arrow;
• Luminous car position signal;
• Luminous and audible car overload signal;
• Luminous arrows showing the directions of movement.
