4.0
ENG
GLT
Ω
L
IFT
O
PERATION
M
ANUAL
Page | 19
3.3 PUSH-BUTTON PANELS FOR LIFT WITH COLLECTIVE UP-DOWN
OPERATION
The push-button panel for a lift with collective up-down operation consists of the following.
The following buttons and indicators (minimum supply) are provided on the floors:
• Call accepted button, which the user must press to call the lift;
• “Call accepted” signal or blue indicator, showing that the call for the lift has been accepted;
• Luminous arrows showing the directions of movement.
The following buttons and indicators are in the car:
• Call accepted buttons with floor number;
• Yellow alarm button with bell symbol;
• Door reopening button with outline of double arrow;
• Luminous car position signal;
• Luminous and audible car overload signal;
• Luminous arrows showing the directions of movement.
