Gocycle
®
Owner’s Manual Version August 2015
© Karbon Kinetics Limited. All Rights Reserved. 14
5.4
Unfolding the Frame
Figure 5-15
Pull fold lock pin to release
spring.
Figure 5-16
Open frame.
Spring
