Owner’s Manual Version August 2015
© Karbon Kinetics Limited. All Rights Reserved. 45
Figure 8-12
Adjusting the alignment of
the rear mudguard: use a
Phillips head screwdriver to
tighten the two screws once
you have aligned the rear
mudguard with the rear tyre.
8.5 Lightweight Display Stand
Figure 8-13
Fitting the lightweight display
stand.
8.6 Antitheft Bolts for PitstopWheel
Figure 8-14
Antitheft screws for the
PitstopWheel can be fitted in
three places. These can be
ordered from
www.gocycle.com.
Tighten to 5Nm torque.
Tighten to 4 Nm torque.
