8.11 Fitting the Heavy-Duty Kickstand
Figure 8-46
Fit bolt through rear luggage
arm as shown.
Figure 8-47
Separate frame to allow
access to tightening bolt.
Figure 8-48
Kickstand in the up position
Remove lightweight
display stand if
fitted.
Bolt
Heavy-duty
kickstand
Tighten to
10Nm torque.
