Gocycle G1 - Fitting the Rear Mudguard

Gocycle
®
Owner’s Manual Version August 2015
© Karbon Kinetics Limited. All Rights Reserved. 22
Figure 5-37
Remove PitstopWheel.
5.7 Fitting the Rear Mudguard
Figure 5-38
Fit rear mudguard.
Figure 5-39
Tighten knob.
Strike rim here to
remove wheel.
Hold quick releases
in fully open
position.
