Gocycle G1 - Handlebar Stem

Gocycle
®
Owner’s Manual Version August 2015
© Karbon Kinetics Limited. All Rights Reserved. 9
Figure 5-3
Figure 5-4
Avoid twisting the cables
when assembling the
handlebar stem.
Figure 5-5
Pull lock pin.
Front quick-
release lever
must be open.
Notice notch in
steerer to align
the two parts
and the lock pin.
