Owner’s Manual Version August 2015
© Karbon Kinetics Limited. All Rights Reserved. 20
Figure 5-31
Notice that the fork is not
engaged with the fork lock
pin.
Fork lock pin is not engaged
in fork.
5.6 Attaching the PitstopWheel
Figure 5-32
The quick-releases are
shown in fully open position.
Figure 5-33
Close quick-releases.
Note safe direction and
position to close quick-
releases.
Press here and in
direction of arrow.
Do not push in this
direction!
