6 FITTING THE FRONT AND REAR REFLECTORS
6.1 Small Parts Bag
Figure 6-1
6.2 Rear Reflector
Figure 6-2
Attach rear bracket as shown
to seat post.
Figure 6-3
Attach rear reflector to
bracket as shown.
Front reflector
(WHITE)
Bracket
screw
Front reflector
bracket & rubber
tube shim
Bracket
screw
Rear
reflector
(RED)
Rear reflector bracket
and rubber tube shim
