Gocycle G1 - Fitting the Rear Luggage Arm

Gocycle
®
Owner’s Manual Version August 2015
© Karbon Kinetics Limited. All Rights Reserved. 54
Figure 8-39
Do not carry more than 5kg
of luggage in the front
pannier, but you also should
never exceed the maximum
allowable weight of rider,
clothing and luggage
(including the pannier itself)
of 100kg.
8.10 Fitting the Rear Luggage Arm
Figure 8-40
Rear luggage arm and
mudguard
Figure 8-41
Remove bolts and mudguard
nut.
Remove these two
bolts. Torx head 25.
Remove rear
mudguard nut.
