Owner’s Manual Version August 2015
© Karbon Kinetics Limited. All Rights Reserved. 55
Figure 8-42
Position luggage arm over
shock threaded screw and
align with two Cleandrive
®
bolt holes.
Figure 8-43
Insert and tighten M6 captive
nut with M6 Allen key as
shown (5Nm torque).
Figure 8-44
Insert and tighten special
bolts supplied with rear
luggage arm as shown (5Nm
torque).
Position over shock
threaded screw.
Align with these
holes.
