Gocycle

Owner’s Manual Version August 2015

3. Turn the two bottom bracket lock collars in the direction shown as tightly as you can by hand. Do not use

pliers to tighten this collar as this will overstress the pedal crank bearings.

Figure 9-32

To adjust the

bottom bracket,

first loosen the

bolt shown, then

adjust the collars,

then retighten

bolt.

4. Turn the pedals backward to test that they are not unusually hard to turn. If they are unusually hard to turn,

then you have over-tightened the lock collar and should loosen it slightly.

5. Tighten the M4 lock bolt to 2-3Nm.

Unscrew the two

collars until hand tight.

Then tighten the outer

collar set screw to

3Nm torque.
