Gocycle
®
Owner’s Manual Version August 2015
© Karbon Kinetics Limited. All Rights Reserved. 84
3. Keep 2 cam levers in the
closed position and open one
cam lever fully so that the back
edge touches the next closed
cam lever.
4. Lightly move the cam lever
back and forth to gauge the
extent of the free play.
Free play is defined as the
portion of movement where
there no noticeable pressure
required to move the cam lever
before it engages with the hub.
It is measured at the tip of the
cam lever.
5. If the free play exceeds
10mm at the tip of the cam
lever, use the 4mm Allen key
to reduce this.
