Appendix
BT2.4G Module
RT700i/RT730i USER MANUAL
APPENDIX
BT2.4G Module
Getting Started
Open the bottom base cover
open
Install BT2.4G Module
Follow below step to insert BT2.4G Module
into the slot.
Follow the indicator to insert the module.
BT
rettuC
r
e
sne
psiD
BT
rettuC
resnepsiD
BT
rettuC
resnepsiD
Push the module to the end of the slot.
The Installation Line on BT2.4G Module
must right along with the edge of mainboard.
Otherwise, it might cause signal error.
**** Please prevent below incorrect installation.
* User have to turn off the machine that
can insert BT2.4G module.
BT
rettuC
resnepsiD
BT
rettuC
resnepsiD
Does not parallel with mainboard.
Does not push till the end of slot.
Notice

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Godex RT700i SERIES and is the answer not in the manual?

Godex RT700i SERIES Specifications

General IconGeneral
Print MethodThermal Transfer / Direct Thermal
Max Print Width4.09" (104 mm)
Print Resolution203 dpi
Print Speed7 IPS (177.8 mm/s)
Max Print Length1727 mm (68")
Memory8 MB Flash, 16 MB SDRAM
InterfaceUSB 2.0, Serial RS-232, Ethernet
Processor32-bit RISC CPU
SensorsGap transmissive sensor, Black mark reflective sensor
PowerAC 100-240V, 50/60Hz
Label Width10 - 110 mm
Label Thickness0.06 - 0.25 mm (2.36 - 9.84 mil)
Roll Outer Diameter127 mm (5")
Core Diameter25.4 mm (1")
Dimensions285 mm (W) x 171 mm (H) x 226 mm (D)
Weight5.5 lbs (2.5 Kg)
Operating Temperature41°F to 104°F (5°C to 40°C)
Storage Temperature-4°F to 122°F (-20°C to 50°C)
Operating Humidity30% - 85% non-condensing
CertificationsCE, FCC, RoHS
