Godex RT700i SERIES User Manual

Appendix
1.2
Work with Logitech K810 Keyboard
After install BT2.4G Module,
the icon will be appear on LCD display.
Button
Switch
Press

Key3 Secs to Enter Menu
Ready
The indicators are flashing and can be detected by wireless.
Connect printer and wireless keyboard
Turn on the switch and push the Connect Button.
就緒
Instruction icon
**** Different operation with different wireless keyboard. Please refer to wireless keyboard user manual.
** There have pin code default value is 9200 of K810 if user change SSP setting from enable to disable the printer will
be asked to key in pin code.
Notice
Ready

Godex RT700i SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max Print Width	4.09" (104 mm)
Print Resolution	203 dpi
Print Speed	7 IPS (177.8 mm/s)
Max Print Length	1727 mm (68")
Memory	8 MB Flash, 16 MB SDRAM
Interface	USB 2.0, Serial RS-232, Ethernet
Processor	32-bit RISC CPU
Sensors	Gap transmissive sensor, Black mark reflective sensor
Power	AC 100-240V, 50/60Hz
Label Width	10 - 110 mm
Label Thickness	0.06 - 0.25 mm (2.36 - 9.84 mil)
Roll Outer Diameter	127 mm (5")
Core Diameter	25.4 mm (1")
Dimensions	285 mm (W) x 171 mm (H) x 226 mm (D)
Weight	5.5 lbs (2.5 Kg)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
Operating Humidity	30% - 85% non-condensing
Certifications	CE, FCC, RoHS
