Programming
English
MENU 2
2.1 Opening and Closing Speed
motor LED colour red:
Option to select 1 of 4 pre-dened speed settings. Default setting is „Normal“.
Note: After 15s. without input, the motor unit quits programming mode.
Please read the steps of this feature rst before starting.
1. Press and hold the OPEN+CLOSE buttons until the LED on the motor unit slowly ash-
es white (after ~8s.) (First the LED will turn white continuously, keep the button(s)
pressed)
2. Repeatedly press OPEN or CLOSE until the LED on the motor unit is red.
3. Shortly press the OPEN+CLOSE buttons to enter the feature menu,
4. The LED on the motor unit now ashes red, at the current setting:
5. Cycle through the options below using OPEN or CLOSE:
1x ash = Normal speed (Default)
2x ash = High speed
3x ash = Low speed
4x ash = Open at low speed - Close at high speed / Custom speed.
6. Conrm and store setting by shortly pressing OPEN+CLOSE buttons.
7. The LED on the motor unit slowly ashes white again for 15 seconds: using the
OPEN or CLOSE buttons another MENU 2 feature can be selected.
8. Otherwise, wait for 15 seconds or shortly press the OPEN+CLOSE buttons to quit
programming.
The LED on the motor unit switches off, the system is ready to use.
To quit programming at any time, repeatedly press the OPEN+CLOSE buttons or wait for 15s.
Changes made at 5 will only be saved if conrmed by pressing the OPEN+CLOSE buttons.
2.2 Intermediate positions
motor LED colour green:
Dene up to 5 intermediate curtain stopping positions, in between the systems end posi-
tions. Default is setting is none. Described below for Dry contact.
Intermediate positions can quickly be recalled by pressing 2x OPEN or 2x CLOSE, within 2s.
The system moves in indicated direction until it reaches next intermediate position.
It is required that at feature 3.1 (p.28) „control mode 1“ is active (default is active).
Note: After 15s. without input, the motor unit quits programming mode.
Please read the steps of this feature rst before starting.
