GOK SmartBox 1 Assembly And Operating Manual

SmartBox
®
1 / SmartBox
®
2 / SmartBox
®
3
12 / 20 part no. 28 100 57 f
Menu
Input function
Input value
7.Relay 2
SmartBox 2
or
7.Relay
[SmartBox 3]
See 7. Relay 1 for the data for Relay 2 (or Relay)
on ______%
off ______%
on ______°C
off ______°C
8.Exit
Press [Enter] to return to display mode
After performing entry steps 1 - 7, the programming process is completed. After confirmation
of step “8.Exit“, the device automatically returns to default display mode; the current tank
content is shown in the display.
Special functions are available under entry steps 9 to 24.
After the end of setup, do not forget to replace the housing cover!
After completing the ASSEMBLY and PROGRAMMING, carrying out a function check is
recommended (FUNCTION CHECK section).
EXAMPLES FOR PROGRAMMING
Example 1: Basement tank for 6000 litres heating oil, litre indication, linear steel tank
Inner height 165cm, (fill level 125cm)
SmartBox
®
1 Standard probe 0 - 250mbar
Step
Entries / selection
1.Measure probe
250mbar
2.Liquid
Heat oil
3.Tank shape
Linear
4.Tank volume
6000L (set with [+] / [-] keys)
5.Filling limit
165.0cm (set with [+] / [-] keys)
5b.Filling limit
95%=157cm (set with [+] / [-] keys)
6.View

View details
Fillspace+Percnt
display 2. line - (set with [+] / [-] keys)
7.Exit
 press [Enter] to see the indication
Heat oil 4.550L
-1.150L 76%
