CAUTION
Risk of damage to the Solar-Log!
The Solar-Log also has an RJ45 socket, which must never be
connected to the RJ45 socket on the inverter!
ONLY connect Solar-Log via the RS485/422 B interface on
the bottom of Solar-Log.
Figure RS485/422 B Terminal Block Connector
Connect the wires as shown in the following diagram:
Solar-Log terminal block connector
Terminal
RJ 45 socket of inverter Pin
1 Pin 3
4 Pin 6
5 Pin 1
6 Pin 2
• Insert the RJ45 plug into any RJ45 socket on the first inverter;
• If only one inverter is to be connected, terminate this;
• Insert the terminal block connector into the Solar-Log
RS485/422 B socket;
