12x3.5-inch NV hard drive configuration
Figure 2-13
25x2.5-inch hard drive configuration
Figure 2-14
2.5.3 Hard drive status indicator
Figure 2-15
Hard drive status indicator description
Table 2-11
2.6 Power Supply
Supports 1 or 2 power modules;
Supports AC or DC power modules;
Supports hot-swapping;
When configured with 2 power modules, supports 1+1 redundant backup;
For power modules configured in the same server, the power module models
must be identical;
