GMC-I Messtechnik GmbH 57
20 Appendix
20.1 Tables for the determination of maximum or minimum display values under consideration of maximum instrument operating uncertainty:
Table 1
Table 2
Table 3
Table 4
Z
L-PE
. (full-wave) / Z
L-N
()
Z
L-PE
. (+/- half-wave)
()
Limit
Value
Max.
Display
Value
Limit
Value
Max.
Display
Value
0.10 0.07 0.10 0.05
0.15 0.11 0.15 0.10
0.20 0.16 0.20 0.14
0.25 0.20 0.25 0.18
0.30 0.25 0.30 0.22
0.35 0.30 0.35 0.27
0.40 0.34 0.40 0.31
0.45 0.39 0.45 0.35
0.50 0.43 0.50 0.39
0.60 0.51 0.60 0.48
0.70 0.60 0.70 0.56
0.80 0.70 0.80 0.65
0.90 0.79 0.90 0.73
1.00 0.88 1.00 0.82
1.50 1.40 1.50 1.33
2.00 1.87 2.00 1.79
2.50 2.35 2.50 2.24
3.00 2.82 3.00 2.70
3.50 3.30 3.50 3.15
4.00 3.78 4.00 3.60
4.50 4.25 4.50 4.06
5.00 4.73 5.00 4.51
6.00 5.68 6.00 5.42
7.00 6.63 7.00 6.33
8.00 7.59 8.00 7.24
9.00 8.54 9.00 8.15
9.99 9.48 9.99 9.05
R
E
/ R
ELoop
()
Limit
Value
Max.
Display
Value
Limit
Value
Max.
Display
Value
Limit
Value
Max.
Display
Value
0.10 0.07 10.0 9.49 1.00 k 906
0.15 0.11 15.0 13.6 1.50 k 1.36 k
0.20 0.16 20.0 18.1 2.00 k 1.81 k
0.25 0.20 25.0 22.7 2.50 k 2.27 k
0.30 0.25 30.0 27.2 3.00 k 2.72 k
0.35 0.30 35.0 31.7 3.50 k 3.17 k
0.40 0.34 40.0 36.3 4.00 k 3.63 k
0.45 0.39 45.0 40.8 4.50 k 4.08 k
0.50 0.43 50.0 45.4 5.00 k 4.54 k
0.60 0.51 60.0 54.5 6.00 k 5.45 k
0.70 0.60 70.0 63.6 7.00 k 6.36 k
0.80 0.70 80.0 72.7 8.00 k 7.27 k
0.90 0.79 90.0 81.7 9.00 k 8.17 k
1.00 0.88 100 90.8 9.99 k 9.08 k
1.50 1.40 150 133
2.00 1.87 200 179
2.50 2.35 250 224
3.00 2.82 300 270
3.50 3.30 350 315
4.00 3.78 400 360
4.50 4.25 450 406
5.00 4.73 500 451
6.00 5.68 600 542
7.00 6.63 700 633
8.00 7.59 800 724
9.00 8.54 900 815
R
INS
M
Limit
Value
Min.
Display
Value
Limit
Value
Min.
Display
Value
0.10 0.12 10.0 10.7
0.15 0.17 15.0 15.9
0.20 0.23 20.0 21.2
0.25 0.28 25.0 26.5
0.30 0.33 30.0 31.7
0.35 0.38 35.0 37.0
0.40 0.44 40.0 42.3
0.45 0.49 45.0 47.5
0.50 0.54 50.0 52.8
0.55 0.59 60.0 63.3
0.60 0.65 70.0 73.8
0.70 0.75 80.0 84.4
0.80 0.86 90.0 94.9
0.90 0.96 100 106
1.00 1.07 150 158
1.50 1.59 200 211
2.00 2.12 250 264
2.50 2.65 300 316
3.00 3.17
3.50 3.70
4.00 4.23
4.50 4.75
5.00 5.28
6.00 6.33
7.00 7.38
8.00 8.44
9.00 9.49
R
LO

Limit
Value
Max.
Display
Value
Limit
Value
Max.
Display
Value
0.10 0.07 10.0 9.59
0.15 0.12 15.0 14.4
0.20 0.17 20.0 19.2
0.25 0.22 25.0 24.0
0.30 0.26 30.0 28.8
0.35 0.31 35.0 33.6
0.40 0.36 40.0 38.4
0.45 0.41 45.0 43.2
0.50 0.46 50.0 48.0
0.60 0.55 60.0 57.6
0.70 0.65 70.0 67.2
0.80 0.75 80.0 76.9
0.90 0.84 90.0 86.5
1.00 0.94 99.9 96.0
1.50 1.42
2.00 1.90
2.50 2.38
3.00 2.86
3.50 3.34
4.00 3.82
4.50 4.30
5.00 4.78
6.00 5.75
7.00 6.71
8.00 7.67
9.00 8.63
