2.5. Adjusting the position of the brake lever
Undo the screws on the handlebar clamp with a Torx T25 spanner to twist and move the
brake levers on the handlebars. First tighten the top screw until the brake lever and clamp
are adjacent to each other without a gap. Then tighten the bottom screw (see torque table).
The brake levers are configured correctly when your fingers can reach the brake
levers when your arms are outstretched. The wrist should be stretched out as much
as possible.
2.6. Adjusting the width of the brake lever
The brake lever grip can be adjusted to the size of
your hand with the aid of a Torx T25 key. Adjust the
brake lever so that you can grab it quickly and
safely
while applying a large
handforce. The brake lever
must not come into contact with the handlebars.
If you can pull the brake lever as far as the handlebars, you cannot apply the full
braking force during a full braking. This increases the braking distance. Risk of
accident!
2.7. Assembling the side reflectors (S-Pedelec only)
The self-adhering side reflectors are fixed to the
down tube of the frame on the side.
