5.9. Assembling the pedals
Apply a think layer of grease to the threads on the
pedal axis and crank.
First of all, screw the pedal loose by hand. Make sure
the parts are positioned at the correct angle to each
other and do not tilt.
Move the crank into a horizontal position so that the
pedal is facing the front wheel.
Place the open end spanner SW15 (0,59 in) on the
pedal axle and hold the crank firmly on the opposite
side.
Tighten the pedal with the torque according to the
data provided by the
The right pedal has a right-hand thread, the left pedal a left-hand thread to the
pedal axle for assembly onto the cranks. The right pedal is screwed in a clockwise
direction and the left pedal anti-clockwise.
