Now place the components on the front of the
pedals and push it from behind with the second
mounting wedge. Then set the M4 nuts on the
bolts. Please note that the inclination of the wedge
is placed in a way, that the reflector is perpendicular
to the pedal surface.
Now tighten the screws using the above tool. Do not
tight the screws firmly. You should be able to move
the reflector
Align the center of the reflector housing and tighten
the screws permanently.
Tip: If you hold still while tightening the screw and
turn with the wrench, the housing slips less.
Click the reflector to the reflector housing.
Repeat the process with two pedals and on both sides
of the pedal.
