04836
Accessories
Use Only Genuine Graco Parts and Accessories
Air
Atomizing Hose, Buna-N
200 psi (14 bar) Maximum Working Pressure
0.312 in. (7.9 mm) ID; coupled 1/4 npsm(f) swivel both
ends; neoprene cover
210–866
15 ft (4.7 m) long
210–867
25 ft (7.6 m) long
210–868
50 ft (15.2 m) long
Throat Seal Liquid (TSL) 206–995
1 quart (0.97 liter) non-evaporation lubricant for air and
fluid packings.
Gravity Cup Lid 1
10–750
Replacement lid for Gravity Cup PC–45 105–702.
Siphon Cup PC–12 105–701
20.4 oz. (600 cc) capacity; 1/4 npsm(f)
Replacement diaphragm available.
Order part number 106–678.
Replacement lid gasket available.
Gasket is polyethylene.
Order part number 106–680.
Gravity Cup PC–4S 105–702
13.6 oz. (400 cc) capacity; 1/4 npsm(f)
Manual
Change Summary
The
manual was revised to include the following changes:
D
The maximum working pressure was changed to 100 psi.
D
CE symbol was added to the front page.
D T
ext and warnings were updated for CE requirements.
