4 307-378
Ordering
Charts
The
charts below provide a cross reference between
identification numbers stamped on the parts and the
Graco part number
. Chart 1 shows the complete gun
assemblies available, grouped by basic gun type.
Chart 2 shows fluid nozzle/needle combinations. Chart
3 shows the air caps available.
The following is an example of how to use these
charts:
D Y
our application calls for a
pressure feed gun
.
Chart 1
shows this to be a
P600 basic gun
.
D
Using
Chart 2
, the flow rate required and fluid vis
-
cosity call for an
02 fluid nozzle and needle
combi-
nation
.
D
By using
Chart 3
, you determine that the
02 air cap
is best for the application.
D
This makes your combination a
P600–02–02
.
Chart
1
shows that the
Graco part number
for this combi
-
nation is
217–601
.
Chart 1: Gun Combinations Available
P600:
Pressure Feed Guns
Combinations:
Ordering
Part No.
Gun Nozzle
See Chart 2
Air Cap
See Chart 3
217–600 P600 0 0
217–601 P600 02 02
S600: Siphon Feed Guns
Combinations:
Ordering
Part No.
Gun Nozzle
See Chart 2
Air Cap
See Chart 3
217–602 S600 2 2
217–605 S600 3 31
G600:
Gravity Feed Guns
Combinations:
Ordering
Part No.
Gun Nozzle
See Chart 2
Air Cap
See Chart 3
217–607 G600
2
21
217–609 G600 3 31
Terms:
Light Fluid:
19 to 24 seconds (No. 2 Zahn cup). Auto, furniture, appliances, fine-finish metallics, top coats, lacquer
,
enamel primers.
Medium Fluid:
22 to 41 seconds (No. 2 Zahn cup). Contact adhesive, latex, maintenance paints, textures, primers,
epoxies, vinyls, high flow – high viscosity
.
Heavy Fluid:
Mastics, block fillers, roof coating, sound deadeners, adhesive, textures.
