Ram Models
3A0233B 3
Ram Models
This table lists ram models that replace rams included with Graco bulk supply systems that have older style rams.
Ram models without integrated air controls utilize the air controls of the compatible system.
Pump Mounting Chart
This table lists the parts necessary to mount various Graco pumps on the ram. Refer to pages 11-12 for mounting
instructions. See Accessories on page 24 for parts.
For pump mounting and application information, contact your Graco distributor.
Ram
Model Size Style Compatible System
Replaces
Ram Platen Air Controls
257435 3 in. D200 Not specified 207279 NA Integrated air controls
with pump regulator
257452 3 in. D200 Hydra-Mate systems 196079 55 gallon
EPDM
NA
257453 3 in. D200 Hydra-Mate systems 196708 55 gallon
neoprene
NA
24C769 3 in. D200 8900 Proportioner 232110 55 gallon
EPDM
Integrated air controls
without pump regulator
257461 3 in. D200 1:1 Extruder 954419 NA NA
Pump Type
Ram Mounting Kit
224829
Platen Mounting Kit
222776
Monark
®
and President
®
Check-Mate
™
450 Pumps
✔✔
Bulldog
®
and Senator
®
Check-Mate
™
450 Pumps
✔
King
™
, Bulldog
®
, and Senator
®
Check-Mate
™
800 Pumps
✔
King
™
Check-Mate
™
1000 Pumps
✔
King
™
, Bulldog
®
, and Viscount
®
Check-Mate
™
2100 Pumps
✔
King
™
, Bulldog
®
, and Senator
®
Power-Flo
®
Pumps
✔
Monark
®
and President
®
Check-Mate
™
200 Pumps
✔
Bulldog and King Pumps with intake housing mounting flange
✔
Fire-Ball 300, 50:1 247335 and 247336
Fire-Ball 425, 10:1, 50:1, 75:1 247335 and 247337
