Component Identification
6 3A0233B
Component Identification
D200 Rams
Key:
ARam Assembly
B Platen (see F
IG. 3)
C Integrated Air Controls (see F
IG. 2)
D Platen Bleed Port
E Blowoff Air Supply Line (see F
IG. 12)
F Platen Lift Rod
G Main Air Line (not supplied)
H Air Line Drain Valve (not supplied)
J Air Filter (not supplied)
K Bleed Type Air Shutoff Valve (not supplied)
FIG. 1: Typical Installation
257435 Model Shown
A
Lift Locations
B
D
C
F
G
K
J
H
