Component Identification
8 3A0233B
Platen Component Identification
Key:
EA Plate
EB Wipers
EG Spacer
EH Cap Screws
EJ Clamps
EK Bleed Handle
EL Bleed Valve
EM Air Assist Body Check Valve
EN Wiper Plate (under wiper)
EP O-ring Seal
FIG. 3: Platen
TI10518A
255663 and 255664, 200 liter (55 gallon)
EB
EJ
EK
EL
EH
EM
EA
