Screens
22 334784G
Screens
Navigate through each screen to set up the pattern controller interface.
• Run screens include the home page and pattern definition.
• Setup screens contain configurable settings for each accessory.
Screen Maps
NOTE: On integrated InvisiPac system, additional chapters are present for hot melt HMI.
Run Screens
Setup Screens
PC Home Events ErrorsPC Control
1. Program Storage
- Purge
2. Pattern Definition
- Pattern
Preview
Press to switch between Run and Setup
PC Setup
1. Event Map
2. Line Mode
3. Trigger Setup
4. General
5. Gun Setup
6. Run Up 1
7. Run up 2
Advanced
1. Display
2. Units
3. USB Settings
4. Software
To Next Page
