Models
334784G 3
Models
Internal Models (HM25c)
Used to upgrade InvisiPac HM25c systems to include pattern control.
* Order kit 17F712 to upgrade to PC-8e.
Internal Models (HM25 and HM50)
Used to upgrade InvisiPac HM25 and HM50 systems to include pattern control.
External Integrated Models
Used to connect a separate pattern control enclosure to an InvisiPac system (compatible with all InvisiPac systems)
External Stand Alone Models
Used for applications without an InvisiPac system
Approvals Related Manuals
Part Type Description Contents
25M526 PC-8* Time or distance mode, no encoder Pattern controller
Part Type Description Contents
24X640 PC-8 Time or distance mode, no encoder Internal pattern controller
24X641 PC-8e Time or distance mode, with or without encoder
Run up control (optional)
Internal pattern controller
Key token for encoder and run up
Part Type Description Contents
24X523 PC-8 Time or distance mode, no encoder Pattern controller
24X524 PC-8e Time or distance mode, with or without encoder
Run up control (optional)
Pattern controller
Key token for encoder and run up
Part Type Description Contents
24X525 PC-8 Time or distance mode, no encoder Pattern controller
Advanced display module
24X526 PC-8e Time or distance mode, with or without encoder
Run up control (optional)
Pattern controller
Advanced display module
Key token for encoder and run up
Part Description Approvals
127971 External pattern controller CE, ETL, cETL
24W293 Internal pattern controller
(HM25c)
CE, ETL, cETL
24X521 Internal pattern controller
(HM25 and HM50)
CE, ETL, cETL
24E451 Advanced display module CE, ETL, cETL
Part Description
3A4938
InvisiPac HM25c Tank-Free
™
Hot Melt
Delivery System
333347
InvisiPac HM25 and HM50 Tank-Free
™
Hot Melt Delivery System
334934 Run Up Pressure Kit
