Overview
334784G 7
Overview
InvisiPac pattern control systems can be integrated with InvisiPac systems or stand alone with any other equipment.
For all installations, the advanced display module (ADM) is used to make programming easy.
PC-8 controllers operate in time or distance mode without an encoder. Up to 8 guns and 4 independent triggers are
supported.
PC-8e controllers include the same features as PC-8 with the addition of distance based control using an encoder,
and run up control using an I/P or V/P pressure regulator.
Features of the PC-8 and PC-8e:
For more information, see Technical Specifications,
page 64.
Feature
Details
Gun outputs
8
Trigger inputs
4
Encoder
2 (PC-8e only)
Run up control
2 (PC-8e only)
Program storage
50
PLC enable / disable
Yes
PLC alarm output
Yes
PLC program select
Yes
Password protection
Yes
Integrated power supply
Yes
