Graco Reactor 2 E-XP2 Repair And Parts

Repair
11.Loosenlocknut(G)byhitting󰘰rmlywitha
non-sparkinghammer.Unscrewpumpfar
enoughtoexposerodretainingpin.Push
retainingwireclipup.Pushpinout.Continue
unscrewingpump.
PumpA
Figure1
1
Flatsidefacesup.
2
LubricatethreadswithISOoilorgrease.
3
Pumptopthreadsmustbenearly󰘱ushwith
bearingface(N).
Note
Steps12and13applytopumpB.
12.Disconnect󰘱uidinlet(C)andoutlet(D).Also
disconnectsteeloutlettubefromheaterinlet.
13.Pushretainingwireclip(E)up.Pushpin(F)
out.Loosenlocknut(G)byhitting󰘰rmlywitha
non-sparkinghammer.Unscrewpump.
PumpB
Figure2
1
Flatsidefacesup.
2
LubricatethreadswithISOoilorgrease.
3
Pumptopthreadsmustbenearly󰘱ushwith
bearingface(N).
54 333024S
