Graco Reactor 2 E-XP2

Repair
Replace Replace
Replace
Fluid Fluid
Fluid
Inlet Inlet
Inlet
Sensor Sensor
Sensor
NOTE: NOTE:
NOTE:
Forelitemodelsonly.
1.PerformShutdown,page46.
2.Disconnectinletsensorcablefromthe
󰘱uidinletassembly.Inspectcablefor
damageandreplaceifnecessary.See
ElectricalSchematics,page103.
Figure6FluidInletSensor
3.Toreplacesensorcable:
a.Openwirebundleandremovesensorcable.
b.CutanywiretiesanddisconnectfromMCM.
SeeElectricalSchematics,page103.
NOTICE NOTICE
NOTICE
Topreventdamagetocable,routeandsecure
cableinwirebundlewithwireties.
4.Replacesensor(602).
Replace Replace
Replace
Flow Flow
Flow
Meter Meter
Meter
NOTE: NOTE:
NOTE:
ForE-30Elitemodelsonly.
1.PerformShutdown,page46.
2.PerformPressureReliefProcedure,page45.
3.Disconnectthe󰘱owmetercable.
4.Disconnectthehose.Removethe󰘱owmeter.
5.Installthenew󰘱owmeterandreconnectthe
hose.
Figure7FlowMeter
6.Connectthe󰘱owmetercable.
7.Enterthek-factorontheSystemScreen2in
theADM.RefertoSystem System
System
2 2
2
inyourReactor2
operationmanual.
60 333024S
