Graco Reactor 2 E-XP2 Repair And Parts

Repair
Repair Repair
Repair
Electric Electric
Electric
Motor Motor
Motor
Removal Removal
Removal
NOTICE NOTICE
NOTICE
Becarefulnottodropordamagethemotor.The
motorisheavyandmayrequiretwopeopletolift.
1.Removethesystemframefromthe󰘱oorand
L-brackets.
2.Removedrivehousingandpumpassemblies.
SeeRepairDriveHousing,page55.
3.Disconnectelectricmotor(101)powercablefrom
port#15ontheMCM.Removeconnectorby
looseningfourterminalscrews.
4.Removemotorshroud(11).Restthemotor
shroudassemblybehindthemotorwithout
strainingthefanpowercable.
5.Disconnectovertemperaturecablefromport
#2onMCM.Cuttiewrapsaroundharnessto
removecable.
6.Removefourscrews(25)holdingmotor(101)to
bracket.Liftmotoroffunit.
Installation Installation
Installation
1.Placemotoronunit.Threadmotor
cablesintoconduitasbefore.See
ElectricalSchematics,page103.
2.Fastenmotorwithscrews(25)untilscrewsare
fullythreadedinframe.Donottightenscrews
untildrivehousingandpumpsareconnectedto
themotor.
3.Installdrivehousingandpumpassemblies,see
Installation,page57.
4.Routemotor(101)powercordfrommotor
throughconduitandconnecttoport#15on
MCM.Routeovertemperaturecableupfrom
motorandconnecttoport#2onMCM.Insert
cablesinconduitandusetiewrapstosecurethe
conduittogether.
5.Connectmotorshroudassemblytomotor(101).
6.Installdrivehousingcoversandmotorcover.
7.Returntoservice.
58 333024S
