Repair

7.PerformPressureReliefProcedure,page45.

8.Removethesystemframefromthe󰘱oorand

L-brackets.

9.Removetwoboltsandnutsandfoldtheelectrical

enclosurebackward.

10.Removescrews(21)andmotorshroud(11).

Restthemotorshroudbehindthemotorwithout

strainingthefanpowercable.

Note

Examinebearinghousing(103)and

connectingrod(105).Ifthesepartsneed

replacing,󰘰rstremovethepump(106),

seeRemovePump,page53.

11.Removecover(60)andscrews(21).

12.Removecyclecounter(121)fromhousingby

removingscrew(122).

13.Disconnectpumpinletandoutletlines.Remove

screws(113),washers(115),andbearing

housing(103).

NOTICE NOTICE

NOTICE

Donotdropgearcluster(104)whenremoving

drivehousing(102).Gearclustermaystay

engagedinmotorfrontendbellordrive

housing.

14.Removescrews(112,119)andwashers(114)

andpulldrivehousing(102)offmotor(101).

Note

TheAsidedrivehousingincludescycle

counterswitch(121).Ifreplacingthis

housing,removescrews(122)and

switch.Reinstallscrewsandswitchon

newdrivehousing.

Figure4

56 333024S
