Graco Reactor 2 E-XP2 Repair And Parts

Repair
Replace Replace
Replace
RTD RTD
RTD
1.PerformShutdown,page46.
2.Waitforheatertocool.
3.Removeheatercover(10).
4.Cutcabletiesaroundthewovenwrapwiththe
RTDcable(212).
5.DisconnectRTDcable(212)fromTCM(453).
6.Loosenferrulenut(N).RemoveRTD(212)from
heaterhousing(201),thenremoveRTDhousing
(H).Donotremovetheadapter(206)unless
necessary.Ifadaptermustberemoved,ensure
thatmixer(210)isoutofthewaywhenreplacing
theadapter.
7.RemoveRTDcable(212)fromwovenwrap.
8.ReplaceRTD(212).
a.ApplyPTFEtapeandthreadsealanttomale
pipethreadsandtightenRTDhousing(H)
intoadapter(206).
b.PushinRTD(212)sotipcontactsheater
element(208).
c.HoldingRTD(212)againstheaterelement,
tightenferrulenut(N)3/4turnpast
󰘰nger-tight.
9.Routewires(S)asbeforethroughwovenwrap
andreconnectRTDcable(212)totheTCM.
10.Replaceheatershroud(10).
11.Followstartupinstructionsintheoperation
manual.TurnonAandBheatsimultaneouslyto
test.Temperaturesshouldriseatsamerate.If
oneislow,loosenferrulenut(N)andtightenRTD
housing(H)toensureRTDtipcontactselement
(212)whenferrulenut(N)isretightened.
Figure12
333024S 67
