Graco Reactor A-XP1

Technical Specifications
3A1570V 63
Reactor A-XP1 Plural Component Proportioner
US Metric
Maximum Fluid Working Pressure 3500 psi 24 MPa, 241 bar
Maximum Air Supply Pressure 125 psi 0.9 MPa, 9 bar
Maximum Air Working Pressure 100 psi 689 MPa, 6.9 bar
Pressure Ratio 35:1
Air consumption
32 scfm (0.9 m
3
/min) 00 tip at 2000 psi stall pressure
Machine Maximum Power with hose 13,000 Watts
Amperage Requirement (Full Load Peak)* 56 amps at 230 V, 1 Phase
45amps at 230 V, 3 Phase
26 amps at 380 V, 3 Phase
Maximum Heater Fluid Temperature 190 °F 88 °C
Maximum Hose Fluid Temperature 180 °F 82 °C
Maximum Ambient Temperature 120 °F 49 °C
Maximum Output 1.5 gal/min at 2000 psi
Output Per Cycle (A and B) 0.017 gal/cycle (0.064 ltr/cycle)
Heater Power 10,200 Watts
Hose Power 2790 Watts
Sound Pressure (see NXT air motor manual) 70.2 dB(A)
Sound Power (see NXT air motor manual) 80.1 dB(A)
Viscosity Range 250-1500 centipoise (typical)
Maximum Fluid Inlet Pressure 300 psi or 15% of output
pressure
2.1 MPa, 21 bar or 15% of
output pressure
Fluid Inlet/Strainer Filter 20 mesh standard
Air inlet Filter Mesh 40 Micron
Component B (Resin) Inlet 3/4 npt(f) swivel
Component A (Isocyanate) Inlet 3/4 npt(f) swivel
Recirculation/Block Hose Connections Iso (A) side: #5 JIC (m); Resin (B) side: #6 JIC (m)
Maximum Heated Hose Length*** 210 ft of 3/8 ID
Weight 310 lb 140.6 kg
Wetted Parts Carbon steel, stainless steel, chrome, aluminum,
Fluoroelastomer, PTFE, nylon
Voltage Tolerance (50/60 Hz)
200-240VAC Nominal, 1 Phase 195-253VAC
200-240VAC Nominal, 3 Phase (Delta) 195-253VAC
350-415VAC Nominal, 3 Phase
(WYE 200-240VAC Line to Neutral)
338-457VAC
*Full load amps with all devices operating at maximum capabilities with 210 ft (64.1 m) of hose.
***210 ft (64 m) of heated hose will produce the maximum allowable heat capacity. 310 ft (94 m) of heated hose
may be used, but will have 25% less heat capacity.
