Graco Simulation XM User Manual

Appendix B - Alarms
94 3A2776K
R5BE Dosing Sizes Are Not
Optimized.
Spray Dosing valve is operating near high
or low timing limits.
Balance A and B fluid hoses. See
XM PFP Mix Manifold manual.
Or change ‘B’ restriction. Check
Restriction screen.
R5DX Uncalibrated system in
Weight Mode
Spray System was not calibrated. Run the Pump and Metering Test
and Calibration for Ratio by
Weight Mode, page 48, and Batch
Dispense or Ratio Test, page 50
to calibrate system for weight
mode. Run system in volume
mode.
Run system in volume mode.
R9BE System detected five R4BF
(Ratio High B) or five R1BF
(Ratio Low B) alarms within
five minutes. Sprayer shuts
down for five minutes for
operator to resolve problem.
Spray See R4BE or R1BE alarm causes. See R4BE or R1BE alarm
solutions. Flush mixed material if
necessary, and purge off-ratio
mixed material in hose.
*T2DA
*T2DB
Temperature Exceeded
Advisory Limits.
Spray Fluid temperature exceeded high
or low limits for more than four
minutes.
Same as T5DA or T5DB.
T3CA
T3CB
A/B Material Heater
Temperature Control
Module Over Temperature
Advisory
Always Module is bad. Replace module.
Cool system down.
T3CH Hose Heater Temperature
Control Module Over
Temperature Advisory
Always Module is bad. Replace module.
Cool system down.
T4CA
T4CB
A/B Material Heater
Temperature Control
Module Over Temperature
Alarm
Always Module is bad. Replace module.
Cool system down.
T4CH Hose Heater Temperature
Control Module Over
Temperature Alarm
Always Module is bad. Replace module.
Cool system down.
T4CX Temperature Over
Temperature Switch
Always Over temperature switch jumper
unplugged.
Replace jumper.
T4DA
T4DB
A/B Material Heater High
Temperature RTD 1 Alarm
Always Heater bad. Repair heater.
RTD bad. Replace RTD.
T4DE Hose High Temperature
RTD 1 Alarm
Always Heater bad. Repair heater.
Splitter cable bad. Replace splitter cable
RTD bad in hose bundle. Replace RTD in hose bundle.
T4DH Hose Heater High
Temperature RTD 2 Alarm
Always Heater bad. Repair heater.
Splitter cable bad. Replace splitter cable
RTD bad in hose heater outlet. Replace RTD in hose water heater
outlet.
Alarm
Code Alarm Problem
When
Active Cause Solution
