Graco Simulation XM User Manual

Appendix B - Alarms
3A2776K 95
*T5DA
T5DB
A/B Material Heater
Temperature Exceeded
Alarm Limits.
Spray Fluid temperature exceeded high
or low alarm limits for more than
four minutes.
If fluid temperature is too low,
return to circulation mode to
increase fluid temperature. Adjust
heater set point if needed. See
Spray, page 40.
If fluid temperature is too high,
lower heater set point, and return
circulation mode to cool. See
Spray, page 40.
Adjust temperature target setpoint.
See Spray, page 40.
T6DA
T6DB
A/B Material Heater RTD 1
Bad Alarm
Always RTD bad. Replace RTD.
RTD disconnected. Connect sensor to system.
T6DE Hose RTD 1 Bad Alarm Always RTD bad. Replace RTD.
RTD disconnected. Connect sensor to system.
T6DH Hose Heater RTD 2 Bad
Alarm
Always RTD bad. Replace RTD in hose heater outlet.
RTD disconnected. Connect sensor to system.
T6F1
T6F2
Tank RTD Failure Advisory Always Temperature sensor is bad Replace temperature sensor
Cable is disconnected or bad Connect temperature sensor cable
to system.
T8DA
T8DB
A/B Material Temperature
Not Rising Alarm
Heater
A/B
Heater bad. Repair heater.
Heater voltage too low. Increase heater voltage to 200 -
240 VAC.
T8DH Hose Temperature Not
Rising Alarm
Hose
Heater
Heater bad. Repair heater.
Heater voltage too low. Increase heater voltage to 200 -
240 VAC.
V1IT Low Voltage CAN Always
24 VDC power supply. Check voltage of power supply.
Voltage should be 23-25 VDC. If
out of tolerance, adjust or replace
power supply.
V1MA
V1MB
A/B Material Heater Low
Line Voltage Alarm
Always Temperature Control Module
power cable is disconnected.
Plug in module power cable.
Heater circuit breaker is off Turn on heater circuit breaker.
V1MH Hose Heater Low Line
Voltage Alarm
Always Temperature Control Module
power cable is disconnected.
Plug in module power cable.
Heater circuit breaker is off Turn on heater circuit breaker.
V2MX Voltage Low Control
Advisory
Always Voltage dropping below 9 Vdc from
power supply.
Change air filter in control filter
regulator. See XM PFP repair
manual.
Check voltage on information
screen.
Alarm
Code Alarm Problem
When
Active Cause Solution
