2. Press the “History” soft key when the phone is in an idle state;
3. Select the entry you would like to call using the navigation arrow keys;
4. Press SEND button to dial out.
Via Phonebook. Dial the number from the phonebook.
1. Press the MENU button to bring up the main menu then enter Contacts; or
Press the Contacts button;
2. Enter Local Phonebook/ Broadsoft Phonebook using the navigation arrow keys;
3. Select the contact you would like to call
4. Press SEND button to dial the selected contact.
Speed Dial from Line Key. Dial the number configured as Speed Dial on Line Key.
1. Go to the phone’s Web GUI🡪Settings🡪Programmable Keys, and configure the Line Key Mode as Speed Dial. Select the account to dial
from, and enter the extension number to be dialed out in Value. Click on “Save VPK” at the bottom of the Web GUI page;
2. Off-hook the phone, or directly press the Speed Dial key to dial out.
Call Return. Dial the last answered call.
1. Go to the phone’s Web GUI🡪Settings🡪Programmable Keys, and configure the Line Mode as Call Return. Select the account to dial
from, no Value must be set for Call Return;
2. Off-hook the phone, or directly press the Call Return key to dial out.
Via Paging/Intercom.
1. Take handset off-hook; or
Press the Speaker button; or
Press the Headset button with the headset plugged in; or
Press an available LINE key to activate the speaker;
2. You shall hear dial tone after off-hook;
3. Press the MENU button to switch from “Dialing” to “Paging” (top left of the LCD screen);
4. Enter the number;
5. Press SEND, * or # keys to dial out.
Figure 21: Call using Paging/Intercom
Note
Pressing the MENU button, users can edit the phone number and choose which account to dial that number by clicking “Edit / Dial” soft key.
Notes
After entering the number, the phone waits for the No Key Entry Timeout (Default timeout is 4 seconds, configurable via Web GUI) before
dialing out. Press SEND or # key to override the No Key Entry Timeout;
