GXP2200EXT Module
The GXP2140/GXP2170 is expandable with GXP2200EXT modules. GXP2140/GXP2170 supports up to 4
extension modules, adding 160 fully programmable phone extensions to the phone.
GXP2200EXT board package contains:
Table 10: GXP2200Ext Packaging
Note:
The GXP2200EXT board is an additional accessory for the GXP2140/GXP2170 and is not included in the
GXP2140/GXP2170 box.
To set up the GXP2200EXT board with the GXP2140/GXP2170, please follow the steps below:
1. On the back of the GXP2140/GXP2170 and the GXP2200EXT, there are slots for connector plate.
Attach the connector plate between the slots for GXP2140/GXP2170 and the GXP2200EXT;
2. Apply the screws provided and securely tighten them in (See Figure 1: GXP2140/GXP2170 Back View
with GXP2200EXT ).
3. Connect the GXP2200EXT board to the GXP2140/GXP2170 via EXT port using the RJ11-RJ11 cable
provided;
4. Install the phone stand on the GXP2140/GXP2170 and the GXP2200EXT board;
5. Power up the GXP2140/GXP2170. The GXP2200EXT board will show the booting up screen with
version information and connecting status;
6. After successfully booting up, the GXP2200EXT board will stay in idle. Press and hold the Left button
for 3 to 5 seconds to check the version information and status.
