Grandstream Networks GXV3370 User Manual

P a g e | 20
GXV3370 User Guide
Version 1.0.0.16
HD Audio
Yes, HD handset and speakerphone with support for wideband audio
Base Stand
Yes, integrated stand with multiple adjustable angles. Wall mountable
QoS
Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based authentication,
256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access
control
Multi-language
English, German, Italian, French, Spanish, Portuguese, Russian, Croatian,
Chinese, Korean, Japanese, and more
Upgrade/ Provisioning
Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload, mass
provisioning using TR-069 or AES encrypted XML configuration file
Power and Green
Energy Efficiency
Universal power adapter included: Input: 100-240VAC 50-60Hz; Output 12VDC
1.5A
Integrated PoE* 802.3af Class 3, PoE+ 802.3at, Class 4
*When using PoE to power up phone, the USB port won’t work.
Physical
Dimension: 252mm (W) x 211mm (L) x 84mm (H)
Unit weight: 1.08kg
Package weight: 1.77kg
Temperature and
Humidity
Operation: 0
o
C to 40
o
C
Storage: -10
o
C to 60
o
C
Humidity: 10% to 90% Non-condensing
Package Content
GXV3370 phone, handset with cord, base stand, universal power supply, network
cable, screen cleaning cloth, quick installation guide, brochure, GPL license
Compliance
FCC: Part 15 (CFR 47) Class B; UL 60950 (power adapter); Part68 (HAC)
CE: EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1,
EN62479, RoHS
RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 4268
IC: ICES 003, RSS 247, CS 03, RSS 102

Grandstream Networks GXV3370 Specifications

General

Brand	Grandstream Networks
Model	GXV3370
Category	IP Phone
Language	English
